上手CUDA编程

文章目录

上手CUDA编程

矩阵加法例子

编写 CUDA C 程序时，要将文件命名为 *.cu，cu文件支持 C/C++ 语法。

比对一下同样的矩阵相加，通过CPU和GPU计算，运算效率的差异。

#include <cuda_runtime.h>
#include <stdio.h>
#include "cudastart.h"

// CPU对照组，用于对比加速比
// nx ny 为矩阵长宽
void SumMatrix2DonCPU(float* Mat_A, float* Mat_B, float* Mat_C, int nx,
                      int ny) {
  float* a = Mat_A;
  float* b = Mat_B;
  float* c = Mat_C;
  for (int j = 0; j < ny; j++) {
    for (int i = 0; i < nx; i++) {
      c[i] = a[i] + b[i];
    }
    c += nx;
    b += nx;
    a += nx;
  }
}

// 核函数，每一个线程计算矩阵中的一个元素。
// nx ny 为矩阵长宽
__global__ void SumMatrix(float* Mat_A, float* Mat_B, float* Mat_C, int nx,
                          int ny) {
  int ix = threadIdx.x + blockDim.x * blockIdx.x;
  int iy = threadIdx.y + blockDim.y * blockIdx.y;
  int idx = ix + iy * ny;
  if (ix < nx && iy < ny) {
    Mat_C[idx] = Mat_A[idx] + Mat_B[idx];
  }
}

// 主函数
int main(int argc, char** argv) {
  // 设备初始化
  printf("Randy strating...\n");
  initDevice(0);

  // 输入二维矩阵，4096*4096，单精度浮点型。
  int nx = 1 << 12;
  int ny = 1 << 12;
  int nBytes = nx * ny * sizeof(float);

  // Malloc，开辟主机内存
  float* A_host = (float*)malloc(nBytes);
  float* B_host = (float*)malloc(nBytes);
  float* C_host = (float*)malloc(nBytes);
  float* C_cal_by_gpu = (float*)malloc(nBytes);
  InitialData(A_host, nx * ny);
  InitialData(B_host, nx * ny);

  // cudaMalloc，开辟设备内存
  float* A_dev = NULL;
  float* B_dev = NULL;
  float* C_dev = NULL;
  CHECK(cudaMalloc((void**)&A_dev, nBytes));
  CHECK(cudaMalloc((void**)&B_dev, nBytes));
  CHECK(cudaMalloc((void**)&C_dev, nBytes));

  // 输入数据从主机内存拷贝到设备内存
  CHECK(cudaMemcpy(A_dev, A_host, nBytes, cudaMemcpyHostToDevice));
  CHECK(cudaMemcpy(B_dev, B_host, nBytes, cudaMemcpyHostToDevice));

  // 二维线程块，32×32
  dim3 block(32, 32);
  // 二维线程网格，128×128
  dim3 grid((nx - 1) / block.x + 1, (ny - 1) / block.y + 1);

  // 测试GPU执行时间
  double GpuStart = CpuSecond();
  // 将核函数放在线程网格中执行
  SumMatrix<<<grid, block>>>(A_dev, B_dev, C_dev, nx, ny);
  CHECK(cudaDeviceSynchronize());
  double gpuTime = CpuSecond() - GpuStart;
  printf("GPU Execution Time: %f sec\n", gpuTime);

  // 在CPU上完成相同的任务
  cudaMemcpy(C_cal_by_gpu, C_dev, nBytes, cudaMemcpyDeviceToHost);
  double cpuStart = CpuSecond();
  SumMatrix2DonCPU(A_host, B_host, C_host, nx, ny);
  double cpuTime = CpuSecond() - cpuStart;
  printf("CPU Execution Time: %f sec\n", cpuTime);

  // 检查GPU与CPU计算结果是否相同
  CHECK(cudaMemcpy(C_cal_by_gpu, C_dev, nBytes, cudaMemcpyDeviceToHost));
  checkResult(C_host, C_cal_by_gpu, nx * ny);

  cudaFree(A_dev);
  cudaFree(B_dev);
  cudaFree(C_dev);
  free(A_host);
  free(B_host);
  free(C_host);
  free(C_cal_by_gpu);
  cudaDeviceReset();
  return 0;
}

具体代码，原博主已经上传到github上了：https://github.com/ZihaoZhao/CUDA_study/tree/master/Sum_Matrix

主要思想就是先对设备进行初始化initDevice(0);，然后初始化主机内存和设备内存。在主机端初始化2个矩阵 A_host、B_host，然后把这2个数组内的值拷贝到设备内存 A_dev、B_dev中。

2维矩阵大小为 $4096 \times 4096$ ，grid网格大小为 $128 \times 128$ ，线程块大小为 $32 \times 32$ ，总线程为 $4096 \times 4096$ ，每个线程处理1个元素。

GPU上处理完后，将设备内存结果拷贝到主机，并与CPU结果进行比较。

编译

CUDA代码文件后缀名是.cu。

编译单文件CUDA程序命令

nvcc -o randy sum_martix.cu

之后会生成一个可执行文件test，使用下面的命令即可运行。

./randy

结果：

Randy strating...
Using device 0: NVIDIA GeForce RTX 3070 Laptop GPU
GPU Execution Time: 0.000816 sec
CPU Execution Time: 0.054139 sec
Check result success!

结果也能看出来，GPU的效率是CPU的 $0.054139 \div 0.000816= 66.35倍 $

查看本机GPU信息

#include <cuda.h>
#include <cuda_runtime.h>

#include <iostream>
int main() {
  int dev = 0;
  cudaDeviceProp devProp;
  cudaGetDeviceProperties(&devProp, dev);
  std::cout << "GPU Device Name" << dev << ": " << devProp.name << std::endl;
  std::cout << "SM Count: " << devProp.multiProcessorCount << std::endl;
  std::cout << "Shared Memory Size per Thread Block: "
            << devProp.sharedMemPerBlock / 1024.0 << " KB" << std::endl;
  std::cout << "Threads per Thread Block: " << devProp.maxThreadsPerBlock
            << std::endl;
  std::cout << "Threads per SM: " << devProp.maxThreadsPerMultiProcessor
            << std::endl;
  std::cout << "Warps per SM: " << devProp.maxThreadsPerMultiProcessor / 32
            << std::endl;
  return 0;
}

结果：

GPU Device Name0: NVIDIA GeForce RTX 3070 Laptop GPU
SM Count: 40
Shared Memory Size per Thread Block: 48 KB
Threads per Thread Block: 1024
Threads per SM: 1536
Warps per SM: 48

本机电脑使用的是英伟达的 GeForce RTX 3070显卡，有40个流式多处理器SM，每个线程块共享内存为48KB，每个线程块有1024个线程，每个SM有1536个线程，每个SM有48个线程束。

内存管理函数

主机和设备各自拥有独立的内存，C 语言通过标准库管理主机的内存，CUDA 提供 API 管理设备的内存：

C语言	CUDA	功能
malloc	cudaMalloc	分配内存
memcpy	cudaMemcpy	复制内存
memset	cudaMemset	设置内存
free	cudaFree	释放内存

主机与设备的数据拷贝，可以使用 cudaMalloc，cudaMemcpy 和 cudaFree 函数，前篇已经介绍过了，看看具体怎么使用

#include <cuda.h>
#include <cuda_runtime.h>
#include <math.h>
#include <sys/time.h>
#include <iostream>
#include <vector>

double CpuSecond() {
  struct timeval tp;
  gettimeofday(&tp, NULL);
  return ((double)tp.tv_sec + (double)tp.tv_usec * 1e-6);
}

int main() {
  float mats[6][4] = {
      {23, 33, 43, 53}, {15, 25, 35, 45}, {12, 22, 32, 42},
      {39, 49, 59, 69}, {20, 30, 40, 50}, {8, 18, 28, 38}
  };
  // copy data to gpu
  std::cout << "mats size: " << sizeof(mats) << std::endl;

  double GpuStart = CpuSecond();
  float *dev_mats;
  cudaError_t err = cudaSuccess;
  err = cudaMalloc((void **)&dev_mats, sizeof(mats));
  if (err != cudaSuccess) {
    printf("Failed to cudaMalloc!");
    return 1;
  }
  cudaMemcpy(dev_mats, mats, sizeof(mats), cudaMemcpyHostToDevice);
  std::cout << "Copied data to GPU.\n";

  // get back copied cuda data
  float host_mats[sizeof(mats) / sizeof(float)];
  cudaMemcpy(&host_mats, dev_mats, sizeof(mats), cudaMemcpyDeviceToHost);
  double gpuTime = CpuSecond() - GpuStart;
  printf("GPU Execution Time: %f sec\n", gpuTime);

  std::cout << "Copied from cuda back to host.\n";
  std::cout << "host_mats size: " << sizeof(host_mats) << std::endl;
  for (int i = 0; i < sizeof(mats) / sizeof(float); i++) {
    std::cout << host_mats[i] << " ";
  }
  std::cout << std::endl;
  cudaFree(dev_mats);

  return 0;
}

结果：

mats size: 96
Copied data to GPU.
GPU Execution Time: 1.244266 sec
Copied from cuda back to host.
host_mats size: 96
23 33 43 53 15 25 35 45 12 22 32 42 39 49 59 69 20 30 40 50 8 18 28 38

专门二维数组拷贝函数

CUDA 避免2维数组在 kernel 运算时损失较高的性能，设计了专用的内存申请函数cudaMallocPitch，设计了cudaMemcpy2D函数在设备间内存拷贝，形参如下

__host__cudaError_t cudaMallocPitch ( void** devPtr, size_t* pitch, size_t width, size_t height )

__host__ cudaError_t cudaMemcpy2D ( void* dst, size_t dpitch, const void* src, size_t spitch, size_t width, size_t height, cudaMemcpyKind kind )

测试代码：

int main() {

  float mats[6][4] = {{23, 33, 43, 53}, {15, 25, 35, 45}, {12, 22, 32, 42},
                      {39, 49, 59, 69}, {20, 30, 40, 50}, {8, 18, 28, 38}};

  size_t width = 4;
  size_t height = 6;
  size_t pitch;

  std::cout << "mats size: " << sizeof(mats) << std::endl;

  double GpuStart = CpuSecond();
  float *dev_mats;
  cudaError_t err = cudaSuccess;
  err = cudaMallocPitch((void **)&dev_mats, &pitch, sizeof(float) * width,
                        height);
  if (err != cudaSuccess) {
    printf("cudaMalloc failed!");
    return 1;
  }
  // copy data to gpu
  cudaMemcpy2D(dev_mats, pitch, mats, sizeof(float) * width,
               sizeof(float) * width, height, cudaMemcpyHostToDevice);
  std::cout << "Copied data to GPU.\n";

  // get back copied cuda data
  float host_mats[sizeof(mats) / sizeof(float)];
  cudaMemcpy2D(&host_mats, sizeof(float) * width, dev_mats, pitch,
               sizeof(float) * width, height, cudaMemcpyDeviceToHost);
  double gpuTime = CpuSecond() - GpuStart;
  printf("GPU Execution Time: %f sec\n", gpuTime);

  std::cout << "Copied from cuda back to host.\n";
  std::cout << "host_mats size: " << sizeof(host_mats) << std::endl;
  for (int i = 0; i < width * height; i++) {
    std::cout << host_mats[i] << " ";
  }
  std::cout << std::endl;
  cudaFree(dev_mats);

  return 0;
}

结果：

mats size: 96
Copied data to GPU.
GPU Execution Time: 1.251606 sec
Copied from cuda back to host.
host_mats size: 96
23 33 43 53 15 25 35 45 12 22 32 42 39 49 59 69 20 30 40 50 8 18 28 38
